HFTS-20-NaClO
HEPHIS
Sodium hypochlorite generator is a device to generate sodium hypochlorite solution by electrolysis of brine, is composed of salt dissolving device, filtering device, salinedilution device, electrolytic electrode assembly, rectifying power supply, automatic control system, storage and adding components, made of pure sodium hypochlorite solution is a strong oxidizing agent, has a strong bactericidal and bleaching ability, is the most widely used disinfectant, mainly used in the disinfection of drinking water disinfection, food processing, industrial or power system circulating water disinfection, hospital or sewage treatment and disinfection.
Hypochlorous acid can act on the cell wall, the virus shell, but also because the molecules of hypochlorous acid is very small, without charge, can penetrate into the bacteria (virus), and bacteria (virus) body protein,nucleic acid and enzyme and other organic polymer oxidation reaction occurs, then kill the pathogenic microorganisms.
Chloride ion permeability also produce hypochlorous acid significantly altered bacteria and virus body is pressed, the cell loss of activity and death.
| HFTS-20-NaClO Configuration List | ||||
| No. | Items | Unit | Nos. | Remarks |
| 1 | 7000±10%mg/L (0.7%±10%) Sodium Hypochlorite Electrolyzer Set | 1 | Piece | Salt Consumption：4.0 Kg/Kg Cl2 |
| DC Power Consumption：4.5KW/Kg Cl2 | ||||
| Concentration of Dilute Brine：3.5% | ||||
| Concentration of Available Chlorine：7000mg/L | ||||
| Solution Production：3.5L/hr | ||||
| Anode Material:Pure Titanium TA1 + Nano Ru & Ir coating | ||||
| Cathode Material: Pure Titanium TA1 | ||||
| Material of Cell :Transparent Acrylic(PMMA) | ||||
| Lige Of Electrodes : 5 Years | ||||
| 2 | High Frequency DC Electrolytic Rectifier Power Supply | 1 | Piece | Rated Output Capacity : 50A/18VDC |
| Input Voltage：AC 220-230V, 50/60Hz | ||||
| Rectifier Type: IGBT High Frequency Switching Power Supply | ||||
| 3 | PLC+HMI (Include System Sofware） | 1 | SET | 7" Touch Screen |
| 4 | Electrical and Control Units | 1 | Batch | Including: DC24V Power Supply / Circuit Breakers/AC Contactors/Thermal Protectors/Relays /Terminals etc. |
| 5 | Water Softener | 1 | SET | Soft Water Output : 0.6mmol/L |
| Soft Water Capacity : 30L/hour | ||||
| 6 | Salt Dissolving Tank | 1 | SET | PE Tank，V=60L With Liqiud Level Switch. |
| 7 | 3% Dilute Brine Tank | 1 | SET | PE Tank，V=60L With Liqiud Level Switch. |
| 8 | 3% Dilute Brine Pump For Electrode | 1 | Piece | Q=6L@ 4 Bar/AC 220-230V, 50/60Hz |
| 9 | Acid Packling Unit | 1 | SET | 5%-6% HCl Solution For Packling Electrolyzer |
| 1 | Piece | PE Acid Tank，V=40L With Liqiud Level Switch. | ||
| 1 | Piece | Packling Pump Q=100L/hr@3Bar/PP /AC 220-230V/N=200W | ||
| 10 | NaClO Solution Storage Tank | 1 | SET | PE Tank，V=80L With Liqiud Level Switch. |
| 11 | Exhaust Hydrogen Blower | 1 | PCS | Q=50m3/hr ,For Dilute Hydrogen to ≤1% |
| 12 | NaClO Solution Dosing Pump | 2 | SETS | Q=24L@2Bar/AC 220-230V, 50/60Hz (One Work & One Standby) |
| 13 | Packing | 1 | SET | Wooden Packaging and Wet Weight 120Kg |
| Remarks About Guarantee / Supply Cycle / Payment | Supply Cycle | 30 Days | ||
| Payment | 100% TT | |||
| Warranty | 1 YEAR | |||
| Electrode Guarantee | 3 YEARS | |||
| Size of Generator | 150(L)×100(W)×120(H)cm | |||
